Description
1.0 Introduction
The VGA to HDMI is a high-definition video converter which converts analog PC RGBHV and analog audio signal to digital HDMI signal. It allows you to connect the VGA
(HD-15 connector) output from the PC to the digital HDMI input of the latest HD ready plasma, LCD, LED or DLP TV. Its high bandwidth capability supports a wide range of PC and HDTV resolutions.This cable design with a built in audio and USB power cable,which make you no need to add extra audio and power adaptor,it will be more easy to connect the PC to TV,and without worry about to miss the parts when you take along with you.
1.1 Features
1. Plug and play.
2. No extra power
3. HDMI is compliant with HDMI1.3.
4. VGA input Supports up to 1920×1080@60Hz.
2.0 SPECIFICATIONS
1. Input ports: 1xVGA, 1×3.5mmPhoneJack.
2. Output ports: 1xHDMI
3. Input/Output Resolution:
800×600@60/72/75/85Hz, 1024×768@60/70/75/85Hz,
1152×864@75Hz,1280×720@60Hz, 1280×768@60Hz,1280×800@60Hz,
1280×960@60Hz,1280×1024@60Hz,
1360×768@60Hz,1440×1050@60Hz,
1440×900@60Hz,1680×1050@60Hz,
1600×1200@60Hz,1920×1080@60Hz,
1920×1200@60Hz
